Chapter 5 Service Instructions
Revision W HF Series X-ray Generators - Service Manual
5-84 Quantum Medical Imaging, LLC
installed. This can be determined by measuring
the mA output (using a Dynalyzer or mAs meter),
of an exposure taken at 40 kVp and the highest
mA station available. The mA measured should be
the same as the indicated mA (within specified
tolerance). If mA output is too low, increase the
+48 VDC voltage output as required, but do not
exceed +55 VDC. Changing this setting will
require verification of proper filament and mA cal-
ibration (refer to Chapter 3, CALIBRATION).
e. +47.5 - +48.5 VDC between A6TP3 and A6TP1 (if necessary,
adjust A6R17 to obtain this voltage).
6. Access Service Mode, AD Calibration menu. Verify +15 VDC, -15
VDC, +24 VDC, and +24V Brake voltages are within tolerance per
Table 3-8. If not, calibrate in accordance with "A/D Calibration
Procedure" in Chapter 3, Calibration (ODYSSEY) or Appendix B
(DiRex Integration generators), or Appendix D (all other inte-
grated generators.
Line Monitor Board A8 Removal
Line Monitor PCB Usage: AY40-022T1 - Used on Single-Phase Systems;
AY40-022T2 - Used on 208-240 VAC Three Phase Systems w/AID High
Speed Starter; AY40-022T3 - Used on 380-480 VAC Three-Phase Systems
w/AID High Speed Starter; AY40-053S2 - Used on 208-240 VAC Three
Phase Systems w/QMI High Speed Starter; AY40-053S3 - Used on 380-
480 VAC Three Phase Systems w/QMI High Speed Starter
CAUTION! The Line Monitor Board contains elec-
trostatic sensitive devices. Observe proper
grounding precautions before handling the Line
Monitor Board or any other circuit board.
1. Set the power on/standby switch on the Operator Control Panel
(OCP) to the standby ( ) position.
2. Set the ON/OFF circuit breaker CB1 on the generator cabinet to
OFF position.
3. Tag and remove all cables connected to Line Monitor Board A8.
4. Remove four (4) screws securing Line Monitor Board A8 to the
PCB Door and remove the Line Monitor Board.
Line Monitor Board A8 Replacement
Line Monitor PCB Usage: AY40-022T1 - Used on Single-Phase Systems;
AY40-022T2 - Used on 208-240 VAC Three Phase Systems w/AID High
Speed Starter; AY40-022T3 - Used on 380-480 VAC Three-Phase Systems
w/AID High Speed Starter; AY40-053S2 - Used on 208-240 VAC Three
Phase Systems w/QMI High Speed Starter; AY40-053S3 - Used on 380-
