Chapter 1 Specifications
Revision W HF Series X-ray Generators - Service Manual
1-20 Quantum Medical Imaging
NOTE: The above calculations are typical, based upon average usage.
Air circulation around the electronic cabinet must be provided.
This includes the sides, back, front and top of cabinet.
NON-OPERATING ENVIRONMENT
Ambient Temperature: -18°C to +70°C
Relative Humidity: 20 to 95%, non-condensing
Atmospheric Pressure: 500 hPa to 1060 hPa
Figure 1-1. HF Series X-ray Generator Cabinet Dimensions
