Chapter 2 Assembly & Installation
Revision W HF Series X-ray Generators - Service Manual
2-24 Quantum Medical Imaging
The output of the +28 VDC Power Supply is adjusted depending on the type
of Quantum product it will supply power to, as indicated below:
When using the +28 VDC Power Supply Option to provide power for a Model
RS-580 Overhead Tube Crane, the +30 VDC output is intended for operating
the tube crane’s transverse and longitudinal electromagnetic locks (brakes).
Refer to the RS-580 Service Manual for connection instructions.
CAUTION! The Internal +28 VDC Power Supply
Option (QG-28VPS) is only available with 3-phase
generators, and is intended to supply power to a
single, external device.
Tube Rotor Boost Voltage Verification (Systems without High (Dual)
Speed Starter Option)
Ensure Interface Board A9 [P/N AY40-023T (non-digital systems, revision R or
later boards only)/AY40-023T1 (non-digital stored energy systems, revision K
or later boards only)/AY40-034T (digital systems, revision J or later boards
only)] Tube Rotor Boost Voltage Jumper is configured correctly depending on
the type of tube the generator is being interfaced with according to table
below:
Table 2-1a: Internal +28 VDC Power Supply Option (QG-28VPS) Adjustment
Quantum Product Type Adjust Power Supply Output To:
Model RS-580 Overhead Tube Crane +30 VDC
Model QV-800 Universal System +28 VDC
Model QW-420-T, QW-420-T-D Vertical
Tilting Wall Stand
+28 VDC
Table 2-1: Tube Rotor Boost Voltage Jumper Setting
TUBE TYPE
JUMPER
POSITION
ROTOR BOOST VOLTAGE
SETTING
Toshiba E7252X, E7813X,
E7242X, E7239X
Pins 1-2 100 VAC Stator
All others (220 VAC stator) Pins 2-3 220 VAC Stator
