Quantum ODYSSEY HF Series User Manual

Chapter 1 Specifications
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging 1-15
GENERATOR AUXILIARY POWER SUPPLIES
The HF Series X-ray Generator supplies the following supply voltages for powering
X-ray room equipment:
• 24 VDC, 1.5A
• 24 VAC, 150W (collimator lamp not to exceed 150W)
• 115 VAC, 3A
NOTE: The above voltage outputs are not to be used as power
sources for collimator lamps or for inductive loads (e.g.,
motorized tables, solenoids, etc.)
PERFORMANCE SPECIFICATIONS
Table 1-5 provides performance specifications of single-phase (non-stored
energy) HF Series Generators.
* Time measured at 75% of the peak kVp waveform
NOTE: AEC TECHNIQUES SHOULD HAVE EXPOSURE TIMES EXCEEDING 8
MILLISECONDS.
† mAs is tube dependent
Table 1-5. HF Series Single-Phase Generator Performance Specifications
N/A
Cat. No.
QG-3200,
QGV-32
Cat. No.
QG-4000,
QGV-40
N/A
Models
QG-32,
QG-32-5
Models
QG-40,
QG-40-5
Maximum kW N/A 32 40
mA Stations;
Small Focus (S)
Large Focus (L)
N/A
25S, 75S, 150S
100L, 200L, 250L,
320L, 400L, 500L
25S, 75S, 150S
100L, 200L,
250L, 320L,
400L, 500L
kVp Range (kVp) N/A 40-125 40-125
kVp increments (kVp/step) N/A 1.0 1.0
150 kVp option N/A Yes Yes
Time Range (sec.)* N/A 0.001 - 6.3 0.001 - 6.3
Minimum Exposure Time
(sec.)
N/A 0.001 0.001
mAs Range†
N/A 0.025-600 0.025-600
High-Speed Starter N/A No No
Ripple Voltage (output) N/A 5% 5%
