Quantum ODYSSEY HF Series User Manual

Chapter 2 Assembly & Installation
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging 2-49
DC voltage measurement should be made across the (+) and (-) terminals of the
anode DC capacitor bank (i.e., capacitors C13 - C16). The measured voltage
should be +400 (±20) VDC. If not, re-check line voltage and adjust transformer
taps as required to achieve as close to +400 VDC as possible.
Q-VISION OPERATOR CONTROL PANEL - NETWORK SETTINGS VERIFICATION
NOTE! Both the generator cabinet and Q-VISION
network IP addresses are set at the factory to
assure initial communication between the two
components. If the generator will be conncetred
to the internet (such as when utilizing the remote
servicing feature), the factory default IP
addresses must be changed in accordance with
facility Inoformation Technology (IT) administra-
tor’s requirements.
If system is equipped with a Q-VISION operator control panel, verify Generator
Network Settings as follows:
1. Set ON/OFF circuit breaker CB1 on the generator cabinet to ON position.
2. Set the power on/standby switch on the Power/Expose Control Box to the on
() position.
3. The system begins the start up sequence. After a few seconds, the Q-VISION
control panel screen will display.
