Quantum ODYSSEY HF Series User Manual

Chapter 5 Service Instructions
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging, LLC
5-49
SERVICE REPORTS
The HF Series X-ray Generator provides a variety of service reports to assist the
Service Technician in maintaining the proper operation of the system, and to help
troubleshoot problems when they occur.
The way in which Service Reports is accessed and the appearance of the Service
Reports screens differ depending on the operator control panel configuration of
the HF Series X-ray generator. There are three operator control panel configura-
tions:
• ODYSSEY operator control panel
• Q-VISION operator control panel
• Workstation-based operator control panel (generator is integrated with either
a digital radiography (DR) or computed radiography (CR) system)
Refer to the appropriate section that follows depending on the type operator con-
trol panel your system uses.
Accessing Service Reports - ODYSSEY X-ray Generators
The following instructions apply to ODYSSEY HF Series
TM
X-ray Generator
systems. Service Reports are accessed as follows:
1. Set the ON/OFF circuit breaker CB1 on the generator cabinet to
ON position.
2. Set the power on/standby switch on the Operator Control Panel
(OCP) to the standby ( ) position, then to the on ( ) position.
3. The system begins the start up sequence ("Quantum Medical
Imaging" is displayed and "Testing. Standby." is flashing). (See
Figure 5-1.)
4. Within five seconds of start up, press the upper left field select
key to access the Password menu.
5. In the Password menu, enter the default Service/Support Techni-
cian password (58623) using the field select keys next to the cor-
responding numbers.
