Chapter 5 Service Instructions
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging, LLC
5-87
a. Monitor the charger output voltages at A8TP2 (positive sup-
ply) and A8TP3 (negative supply) while allowing the chargers
to recharge the battery tray(s) until each test point rises to
|205| ±1.0 VDC. Note: Charging to these levels may take up
to 2 hours. If these levels cannot be achieved, check the
integrity of the batteries in the affected side of each tray.
b. Once this level has been achieved at A8TP2, adjust A8R70 to
produce Output Limiting, which is indicated when yellow LED
A8D7 begins to blink.
11. Similarly, once this level has been achieved at A8TP3, adjust
A8R66 to produce Output Limiting, which is indicated when yel-
low LED A8D25 begins to blink.
Rotor Drive Board A10 (P/N AY40-013T) Removal
CAUTION! The Rotor Drive Board contains electro-
static sensitive devices. Observe proper ground-
ing precautions before handling the Rotor Drive
Board or any other circuit board.
1. Set the power on/standby switch on the Operator Control Panel
(OCP) to the standby ( ) position.
2. Set the ON/OFF circuit breaker CB1 on the generator cabinet to
OFF position.
3. Tag and disconnect Tube Rotor Cable (AY51-014T-XX) from termi-
nal strip A10TB1-1 through A10TB1-7.
4. Tag and remove plugs connected to receptacles A10J1, A10J3,
A10J4, and A10J5.
5. Remove four (4) hex nuts securing Rotor Drive Board A10 to the
PCB Door and remove the Rotor Drive Board.
Rotor Drive Board A10 (P/N AY40-013T) Replacement
CAUTION! The Rotor Drive Board contains electro-
static sensitive devices. Observe proper ground-
ing precautions before handling the Rotor Drive
Board or any other circuit board.
1. Place the new Rotor Drive Board A10 on the PCB Door and secure
using four (4) hex nuts.
2. Re-connect plugs to receptacles A10J1, A10J3, A10J4, and A10J5
on Rotor Drive Board.
3. Re-connect Tube Rotor Cable (AY51-014T-XX) wires to terminal
strip terminals A10TB1-1 through A10TB1-7.
4. Set the ON/OFF circuit breaker CB1 on the generator cabinet to
ON position.
NOTE
Rotor Drive Board
A10 (AY40-013T)
is not used on
systems equipped
with Dual (High)
Speed Starter
option (QG-HSS
[external] or Q-
HSS [internal]).
