Chapter 2 Assembly & Installation
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging 2-5
Electrical Requirements
In addition to providing for the physical requirements of the equipment,
it is also vital to prepare for the power requirements. Refer to Chapter
1, SPECIFICATIONS for model-dependent power specifications. This
information should be used to prepare system wiring and cabling.
UNPACKING
The HF Series x-ray generator is shipped in a single crate. To unpack, pro-
ceed as follows:
1. Remove packing list and use it as a guide to open the remaining cartons.
Do not dispose of packing material until packing list is matched with
actual parts received. Should there be a shortage or damage, notify
Quantum Medical Imaging, LLC.’s customer service department immedi-
ately. The manufacturer is relieved of any responsibility for damage dur-
ing shipment after unit is picked up by the carrier.
WARNING! The X-ray generator cabinet can
weigh as much as 430 lbs. (195 kg), depend-
ing on configuration. Use lifting straps and
hoist or other suitable lifting device to trans-
port generator. The H.V. Tank weighs
approximately 100 lbs. and requires two per-
sons to lift.
2. Remove the Generator Cabinet from its crate (lifting straps and hoist or
other suitable lifting device is recommended).
3. Using a hand truck from the rear side of the cabinet, lift the generator
and place it as close to its final installation location as possible.
WARNING! When unpacking the generator;
keep upright at all times. Verify there is no
damage caused during shipping, with no
apparent oil leakage from H.V. Tank; check that
the tank lid and oil plug (in tank lid) are secure.
4. Locate the OCP and Pedestal (optional) or Wall Mount Bracket (optional) and
place on the side (not applicable on Q-VISION equipped systems or with inte-
grated systems (e.g., Agfa, Canon, etc.).
NOTE
Examine all car-
tons and crates
carefully at time
of delivery. If
damage is appar-
ent, have deliv-
ery driver write a
"Damaged Ship-
ment Note" on
copies of freight
bill, sign it, and
file appropriate
carrier claim.
Should you dis-
cover concealed
damage, immedi-
ately notify the
transporting
agent and ask
for an
"Inspection of
Damage". Carrier
will not accept
concealed dam-
age claim if filed
after 15 days
from date of
receipt of mer-
chandise.
