Chapter 1 Specifications
Revision W HF Series X-ray Generators - Service Manual
1-16 Quantum Medical Imaging
Refer to Table 1-6 for performance specifications of single-phase stored energy (SE) HF
Series Generators.
* Maximum exposure time is a function of kV and mAs settings and the age of the
batteries; Time measured at 75% of the peak kVp waveform
NOTE: AEC TECHNIQUES SHOULD HAVE EXPOSURE TIMES EXCEEDING 8
MILLISECONDS.
 mAs is tube dependent; the generator may not reach maximum mAs due to tube type.
In AEC mode, the mAs is limited to 600.
Table 1-6. HF Series Single-Phase STORED ENERGY Generator Performance Specifications
N/A
Cat. No.
QG-3200-SE,
QGV-32-SE
Cat. No.
QG-4000-SE,
QGV-40-SE
Cat. No.
QG-5000-SE,
QGV-50-SE
N/A
Model QG-32-SE
(STORED
ENERGY)
Model QG-40-SE
(STORED
ENERGY)
Model QG-50-SE
(STORED
ENERGY)
Maximum kW N/A 32 40 50
mA Stations;
Small Focus (S)
Large Focus (L) N/A
25S, 50S, 75S, 150S
100L, 160L, 200L,
250L, 320L, 400L
25S, 50S, 75S, 150S
100L, 200L, 250L,
320L, 400L, 500L
25S, 50S, 75S,
150S
100L, 200L, 250L,
320L, 400L, 500L,
600L
kVp Range (kVp) N/A 40-125 40-125 40-125
kVp increments
(kVp/step)
N/A 1.0 1.0 1.0
150 kVp optional? N/A No No No
Time Range
(sec.)*
N/A 0.001 - 6.3 0.001 - 6.3 0.001 - 6.3
Minimum Expo-
sure Time (sec.)*
N/A 0.001 0.001 0.001
mAs Range

N/A 0.025-400 0.025-500 0.025-500
High-Speed Starter N/A No No No
Ripple Voltage
(output)
N/A 5% 5% 5%
