Chapter 3 Calibration
Revision W HF Series X-ray Generators - Service Manual
3-72 Quantum Medical Imaging, LLC
* Only required when generator is equipped with 150 kV option.
** If indicated time setting is not allowed based on installed tube, use highest time setting
available.
IMPORTANT NOTE: Upon completing verification
procedures, it is recommended that the Q-Ware
program be used to upload calibration data and
APR technique data (if APR editing was per-
formed) to backup to your laptop the generator
data in case a problem occurs that requires a fac-
tory reset and/or re-calibration of the generator.
To obtain a copy of the Q-Ware program, contact
Quantum Medical Imaging’s Customer Service
Department.
Table 3-14. Maximum Deviation Data Sheet
kVp mA Time** mAs Initials
1
SETTING 45 200L 50 mS 10
MEASURED
2
SETTING 45 25S 5000 mS 125
MEASURED
3
SETTING 60 200L 2000 mS 400
MEASURED
4
SETTING 80 100L 3200 mS 320
MEASURED
5
SETTING 100 200L 25 mS 5
MEASURED
6
SETTING 100 75S 2000 mS 150
MEASURED
7
SETTING 125 100L 100 mS 10
MEASURED
8* SETTING 140 500L 100 mS 50
MEASURED
