Chapter 5 Service Instructions
Revision W HF Series X-ray Generators - Service Manual
5-32 Quantum Medical Imaging, LLC
No HSS
Connected
No High Speed Starter detected
when selected
1. If system is non-high speed starter
configuration (i.e., no high speed
starter is installed), verify the rotor
selected in the Service/Config/
Rotor is not set to "AID HSS" or
"QMI HSS". If so, change to cor-
rect setting.
2. Verify High Speed Starter is prop-
erly connected. If equipped with
QMI internal high speed starter,
verify following connections are
good:
• J2-8 on HSS Control Board
A20A1 (AY40-035S) and J8-8
on Logic Board A1 (AY40-
006S)
• J2-9 on HSS Control Board
A20A1 and J8-9 on Logic
Board A1
No
HV
High-Voltage transformer or
Power Module not functioning
properly.
Call Technical Service/Support.
No Univer-
sal
Equipped
AUX receptor selected, but Gen-
erator is not equipped with Univer-
sal Option.
Select the WALL or TABLE receptor
or NONE.
Not
Rotating
Systems without a high-speed starter:
Table 5-1. Error Messages and Possible Cause(s)
Error
Message
Possible Cause(s)
Remedial Action
