Appendix D Calibration (Using Generator Service Tools)
Revision W HF Series X-ray Generators - Service Manual
D-46 Quantum Medical Imaging, LLC
TABLE RECEPTOR/FILM
SCREEN
1. Perform "Ion Chamber Balancing" procedure for
table ion chamber.
2. Perform "Base Optical Density (OD) Calibration":
a. Set desired optical density
b. Set "Offset" to 1200.
c. Adjust ion chamber’s MASTER GAIN potenti-
ometer until base density is achieved in
acquired images.
4. Perform "AEC kVp Calibration".
Table D-2. DR System AEC Calibration Procedure Sequence
FILM/SCREENS TO BE
CALIBRATED
REQUIRED AEC CALIBRATION PROCEDURES/
SPECIAL INSTRUCTIONS
