Quantum ODYSSEY HF Series User Manual

Chapter 2 Assembly & Installation
Revision W HF Series X-ray Generators - Service Manual
2-28 Quantum Medical Imaging
Table 2-3: AID High Speed Starter DIP Switch Settings
TUBE TYPE
START
VOLTAGE
(180 HZ)
RUN
VOLTAGE
(180 HZ)
HSS SWITCH
SW1 (BOOST
TIME)
HSS SWITCH
SW2 (BRAKE
TIME)
TOSHIBA
E7813X,
E7252X
220 VAC
(#6 tap*)
60 VAC
(75 VAC #3
tap*)
1.2 seconds:
SW1-1 = OFF
SW1-2 = ON
SW1-3 = ON
SW1-4 = OFF
SW1-5 = OFF
2.0 seconds:
SW2-1 = OFF
SW2-2 = ON
SW2-3 = OFF
SW2-4 = ON
SW2-5 = OFF
TOSHIBA
E7254X,
E7255X
490 VAC (use
370 VAC tap
#10*)
165 VAC
(75 VAC #3
tap*)
2.0 seconds:
SW1-1 = OFF
SW1-2 = ON
SW1-3 = OFF
SW1-4 = ON
SW1-5 = OFF
2.0 seconds:
SW2-1 = OFF
SW2-2 = ON
SW2-3 = OFF
SW2-4 = ON
SW2-5 = OFF
VARIAN
(ALL 3 INCH
DIA.)
320 VAC
(use 370 VAC
tap #10*)
100 VAC
(75 VAC #3
tap*)
1.0 seconds
SW1-1 = ON
SW1-2 = OFF
SW1-3 = ON
SW1-4 = OFF
SW1-5 = OFF
2.0 seconds:
SW2-1 = OFF
SW2-2 = ON
SW2-3 = OFF
SW2-4 = ON
SW2-5 = OFF
VARIAN
(ALL 4 INCH
DIA.)
450 VAC
(use 370 VAC
tap #10*)
100 VAC
(75 VAC #3
tap*)
2.2 seconds
SW1-1 = ON
SW1-2 = ON
SW1-3 = OFF
SW1-4 = ON
SW1-5 = OFF
2.0 seconds:
SW2-1 = OFF
SW2-2 = ON
SW2-3 = OFF
SW2-4 = ON
SW2-5 = OFF
