Chapter 2 Assembly & Installation
Revision W HF Series X-ray Generators - Service Manual
2-56 Quantum Medical Imaging
8. Verify the peak voltage at A10TP15 after PREP key has been pressed for at
least 2 seconds (rotor in boost mode) is
greater than
14 V
PEAK
. If necessary,
adjust A10R24 to achieve the correct voltage.
9. Connect a DMM between A10TB1-1 and A10TB1-3.
10. Press the PREP key and verify the voltages as follows:
For 110 VAC stator tubes (Toshiba E7242X, E7813X, E7252X, E7239X)
96 - 140 VAC during boost, 54 - 66 VAC during run
For 220 VAC stator tubes (all others tubes not listed above)
183 - 227 VAC during boost, 54 - 66 VAC during run
11. Install cabinet cover.
12. Proceed with system calibration procedure described in Chapter 3,
CALIBRATION.
