ABL77 Service Manual Chapter 4: Test and Calibration Procedures
Touch Screen Panel Calibration, Continued
Calibration
(continued)
Step Action
10.
If the settings have been accepted, press the ENTER key.
11.
If the settings have not been accepted, the cross will move back into
the center of the screen, and you must start over.
12.
Once the settings have been accepted, the Stylus Properties window
will be displayed. Press ESC on the keyboard.
13.
The Stylus Properties window will disappear and the Control Menu
will be displayed. Press the screen in the top left corner where the
word FILE is displayed.
14.
A drop down menu will appear. Tap the screen where the word
CLOSE is displayed in the drop down menu.
15.
The Control Menu will disappear and the Main Menu will be
displayed on the screen.
Rev. F 4-49
