Chapter 5: Dismantling ABL77 Service Manual
Memory Module
Memory module
Follow these steps to remove the memory module as shown in Figure 5-28.
Step Action
1.
Remove the electronics module.
2.
Remove the analog board.
3.
Remove the interface board.
4.
Disconnect the COM cable from the front of the CPU board by
pulling straight out.
5.
Push the retaining clips out to the top and bottom of the LCD adapter
board. This will cause the board to pop-up.
6.
Slide the LCD adapter board out and up to the right.
7.
Push the second set of retaining clips out at the top and bottom of the
memory module. This will cause the board to pop-up.
8.
Slide the memory module out and up to the right.
Continued on next page
5-46 Rev. F
