Chapter 2: Analyzer Description ABL77 Service Manual
Electronics Module
Introduction
This section provides a description of the electronics module of the ABL77
analyzer.
Components
• Electronics Boards
• Analog board
• Power distribution board
• Interface board
• ChipDisk
• LCD adapter board
• Memory module
• CPU board
• Touch screen controller board
• Battery control board
• Rear Panel with External Connections
• Barcode scanner / keyboard connector
• COM1 port
• Ethernet port
• Power switch
• Charger port
• Battery Pack
Continued on next page
2-34 Rev. F
