ABL77 Service Manual Chapter 5: Dismantling
LCD Adapter Board
LCD adapter
board
Follow these steps to remove the LCD adapter board as shown in Figure 5-28.
Step Action
1.
Remove the electronics module.
2.
Remove the analog board.
3.
Remove the interface board.
4.
Disconnect the COM cable from the front of the CPU board by
pulling straight out.
5.
Push the retaining clips out to the top and bottom of the LCD adapter
board. This will cause the board to pop-up.
6.
Slide the board out and up to the right.
Rev. F 5-45
