Chapter 5: Dismantling ABL77 Service Manual
LCD Display
Introduction
This section describes the procedure for removing the LCD display from the upper
module.
LCD display
removal
Follow these steps to remove the LCD display from the upper housing as shown in
Figure 5-5.
Step Action
1.
Remove the upper module from the analyzer.
2.
Remove the backlight inverter board from the housing bracket.
3.
Remove the two screws holding the disk drive, located on the inside
of the housing bracket.
4.
Remove the four screws holding the housing bracket.
5.
Remove the housing bracket allowing the cables to pass through and
remain with the LCD display.
6.
Remove the disk drive.
7.
Remove the LCD display.
Continued on next page
5-10 Rev. F
