ABL77 Service Manual Chapter 5: Dismantling

LCD Display, Continued

LCD display

removal

(continued)

Figure 5-5

Part Function

1. Backlight inverter board

2. Housing bracket screws

3. Disk drive screws

4. LCD display

5. LCD display cables

6. Touch screen panel

7. Upper housing
