RADIOMETER ABL 77 Series User Manual

Chapter 2: Analyzer Description ABL77 Service Manual
Sample Analysis
The Analysis option on the Main Menu allows the user to initiate a sample
analysis.
Introduction
Pressing the Analysis icon initiates a brief flush of Cal1 solution to ensure the tip
of the inlet probe is filled with fluid.
Analysis – initial
flush
Analysis – phase
1 aspiration
• To begin the sample analysis, the inlet probe flap is lifted to the syringe or
capillary position.
• The Aspirate button is then pressed.
• The primary sample pump then draws in 70 microLiters of sample (see
Figure 2-3).
Figure 2-3
Continued on next page
2-12 Rev. F
