ABL77 Service Manual Chapter 2: Analyzer Description

Sample Analysis, Continued

Analysis – phase

1 aspiration

(continued)

Part Function

1. Cal1 solution (Calibration solution – Level 1)

2. Cal2 solution (Calibration solution – Level 2)

3. Waste bag

4. Cal Pack

5. Main waste line

6. Manifold

7. Manifold luers

8. Side waste line

9. Valves L1, L2 and L3

10. Cassette measuring chamber

11. Roller wheel

12. Inlet probe

13. Waste drain

14. Waste pump

15. Cassette luer

Continued on next page

Rev. F 2-13
