Chapter 9: Spare Parts ABL77 Service Manual
Upper Module Components
Introduction
This section lists the spare parts available for servicing the components of the
upper module. The item number in the left column refers to the exploded diagram
on the following page (A/R = quantity as required).
Item REF Quantity Description
1. 008-932 4 Screw, pan head Phillips m2.5 x 6
2. 992-190 A/R Teflon insulating tape
3. 902-689 1 Backlight inverter board
4. 008-926 4 Screw, pan head Phillips m2.5 x 20
5. 902-688 1 Upper housing bracket
6. 993-080 A/R Copper foil tape
7. 046-117 2 Washer, Flat #4
8. 924-242
924-322
2 Cable clamp, Main top (25 each)
Cable clamp, Main top (5 each)
9. 993-081 A/R Copper cloth tape
10. 910-257 1 Disk drive
11. 311-049 1 LCD display
12. 552-037 1 Touch Screen panel
13. 902-691 1 Upper housing
Continued on next page
9-4 Rev. F
