Chapter 9: Spare Parts ABL77 Service Manual
Lower Module Components
Introduction
This section lists the spare parts available for servicing the components of the
lower module. The item number in the left column refers to the exploded diagram
on the following pages.
See the Lower module, external diagram for references in this table
(A/R = quantity as required).
Lower module -
external
Item REF Quantity Description
1. 902-767 1 Alignment boss
2. 924-241 1 Waste drain mount
3. 008-921 4 Screw, machine tap, pan head Phillips
4. 046-107 6 Washer, #6 flat
5. 902-624 1 Waste pump head
6. 008-920 2 Screw, Phillips #6 x 1¼”
7. 008-919 2 Screw, socket head cap 6-32 x
7
/
8
8. 856-644
856-645
1 Hinge, printer chassis (10 each)
Hinge, printer chassis (2 each)
9. 875-911 1 Spring, extension
10. 924-170
924-319
1 Retaining ring (E-clip) (100 each)
Retaining ring (E-clip) (4 each)
11. 902-687 1 Printer door
12. 902-686 1 Printer module
13. 886-496 1 Printer cover
14. 902-683 1 Cassette fitting tube
15. 848-034 1 Roller wheel
16. 902-690 1 Lower housing
Continued on next page
9-6 Rev. F
