Chapter 9: Spare Parts ABL77 Service Manual
Main Housing
See the Main Housing, front view diagram for references in this table.
Main housing,
front view
Item REF Qty. Description
1. 924-242
924-322
4 Upper module cable clamp (25 each)
Upper module cable clamp (5 each)
2. 008-917 3 Screw, button head cap, 6-32 x 5/8”
3. 834-656 1 Manifold gasket
4. 046-108 2 Washer, external star
5. 032-906 2 Nut, hex, 6-32
6. 924-243
924-320
1 Main housing-center cable clamp, 25
Main housing-center cable clamp, 5
7. 008-918 1 Screw, socket head cap, 6-32 x 5/8”
8. 046-107 1 Washer, #6 flat
Main housing,
front view
diagram
Continued on next page
9-12 Rev. F
