ABL77 Service Manual Chapter 4: Test and Calibration Procedures
Calibration Lines Procedure
Introduction
The Calibration Lines procedure is used to evaluate the function of the internal
tubing and valves that are used to transport calibration solution from the cal pack to
the sensor cassette measuring chamber. If the calibration lines cannot be flushed,
one or more valves may be functioning improperly.
Calibration lines
procedure
Follow the steps below to perform the Calibration Lines procedure.
Step Action
1.
Select Options from the Main Menu.
2.
• Enter a Password as necessary.
• Press OK.
3.
Press Fluidics.
RESULT: The following screen will appear.
4.
• From the pop-up window press Calibration Lines.
• Press Yes to continue.
Continued on next page
Rev. F 4-5
