ABL77 Service Manual Chapter 9: Spare Parts
Electronics Module Components
Introduction
This section lists the spare parts available for servicing the components of the
electronics module. The item number in the left column refers to the exploded
diagrams on the following pages.
(A/R = quantity as required) (* = Trade-in agreement) (⊗ = identical cable used for
two functions)
See the Electronics module, top diagram for references in this table.
Electronics
module, top
Item REF Qty. Description
1. 636-440 2 Cable, main analog (I/O and Sensor)
2. 924-244 1 Electronics insulator card
3. 902-682 1 Analog board *
4. 636-487 1 Cable, analog power
5. 902-838 1 Power distribution board
6. 008-940 2 Screw, pan head Phillips 4-40 x 1½”
7. 046-118 2 Spacer, black nylon 4.4mm
8. 902-681 1 Interface board
9. 902-679 1 CPU board *
10. 365-436 1 ChipDisk
11. 902-678 1 LCD adapter board
12. 008-929 4 Screw, pan head Phillips 4-40 x
7
/
8
”
13. 636-442 1
Cable, A/D ⊗
14. 431-015 1 Coin cell battery
15. 636-443 1 Cable, printer data
16. 046-109 4 Spacer, white nylon 4.5mm
17. 365-438 1 Memory module board
Continued on next page
Rev. F 9-15
