Chapter 9: Spare Parts ABL77 Service Manual
Electronics Module Components, Continued
Electronics
module, top
(continued)
Item REF Qty. Description
18. 636-444 1 Cable, disk drive
19. 636-441 1 Cable, touch screen
20. 365-437 1 Touch screen controller board
21. 636-439 1 Cable, backlight inverter
22. 924-237
924-321
3 Main housing-top cable clamp (25 each)
Main housing-top cable clamp (5 each)
23. 636-494 1 Cable, LCD display
24. 924-245 1 PC Board guides (contains Ref. No. 26)
25. 924-280 1 Cable clamp, ABL77 (contains Ref. No. 27)
26. 008-930 2 Screw, button head cap, 4-40 x ¼”
27. 008-925 4 Screw, pan head Phillips #4 x
3
/
8
”
28. 837-160 1 Bumper strip, 5.5”
29. 886-492 1 Electronics shelf
Continued on next page
9-16 Rev. F
