Chapter 5: Dismantling ABL77 Service Manual
Disk Drive
Introduction
This section describes the procedure for removing the disk drive from the upper
module.
Disk drive
removal
Follow these steps to remove the disk drive from the upper housing as shown in
Figure 5-4.
Step Action
1.
Remove the upper module from the analyzer.
2.
Remove the backlight inverter board.
3.
Remove the two screws holding the disk drive, located on the inside
of the housing bracket.
4.
Remove the four screws holding the housing bracket.
5.
Remove the housing bracket allowing the cables to pass through and
remain with the LCD display.
6.
Remove the disk drive by sliding it out from the bottom.
Continued on next page
5-8 Rev. F
