ABL77 Service Manual Chapter 2: Analyzer Description

Module Descriptions, Continued

Lower module -

Rear

Figure 2-20

Part Function

1. Printer

2. Sensor luer connector

3. Roller pump motor

4. I/O cable connector

5. Valve board

6. Sensor cable connector

7. Opto sensor

8. Manifold

9. Waste pump

Rev. F 2-33
