ABL77 Service Manual Chapter 7: Re-Assembly

Electronic Boards – Module Assembly, Continued

Electronic

boards –

Module

assembly

diagram

(continued)

Part Function

1. Power board screws (2)

2. Power distribution board

3. Power board standoffs (2)

4. CPU board

5. CPU board standoffs (4)

6. Touch screen controller board

7. Touch screen controller cable

8. Power board cable

9. Backlight inverter cable

10. Disk drive cable

11. LCD adapter cable

12. A/D cable

13. CPU board screws (4)

14. Analog power cable

Rev. F 7-53
