ABL77 Service Manual Chapter 7: Re-Assembly

Analog Board, Continued

Analog board

install diagram

Figure 7-35

Part Function

1. I/O cable

2. Sensor cable

3. Analog board

4. Insulator card

5. A/D cable from the battery board

6. A/D cable from the CPU board

7. Analog power cable

8. Touch screen cable

9. Backlight inverter cable

Rev. F 7-61
