Chapter 9: Spare Parts ABL77 Service Manual
Lower Module Components, Continued
See the Lower module, internal diagram for references in this table.
lower module -
internal
Item REF Quantity Description
1. 008-923 2 Screw, button head cap 6-32 x
5
/
16
”
2. 046-107 3 Washer, #6 flat
3. 580-076 1 Roller pump kit
4. 902-811 1 Valve board assembly
5. 886-496 1 Printer cover, top
6. 886-495 1 Printer chassis
7. 902-690 1 Lower housing
8. 902-684 1 Cable, opto sensor
9. 008-925 2 Screw, #4 x
3
/
8
”
10. 046-112 4 Washer, nylon,
11. 924-297 1 Manifold
12. 924-240
924-317
1 Tee tubing connector (40 each)
Tee tubing connector (2 each)
13. 842-335
842-339
2 Silicone tubing, 3 inch (25 each)
Silicone tubing, 3 inch (4 each)
14. 805-167 1 Bulk head connector
15. 032-912 1 Nut, hex ¼-28
16. 580-077 1 Waste pump kit
Continued on next page
