Chapter 9: Spare Parts ABL77 Service Manual
Electronics Module Components, Continued
See the Electronics module, bottom diagram for references in this table.
Electronics
module, bottom
Item REF Qty. Description
1. 636-442 1
Cable, A/D ⊗
2. 008-922 3 Screw, socket button cap 6-32 x
7
/
8
”
3. 032-910 8 Kep nut 6-32
4. 886-491 1 Power connector bracket
5. 636-488 1 Cable, power board
6. 046-104 3 Washer, internal star #6
7. 902-680 1 Battery control board *
8. 636-435 1 Cable, printer power
9. 008-916 4 Screw, socket button cap 6-32 x ¼”
10. 886-490 1 Electronics chassis
11. 636-437 1 Cable, power switch
12. 636-438 1 Cable, Ethernet
13. 636-445 1 Cable, COM port (with hardware)
14. 636-436 1 Cable, barcode gun / keyboard
15. 924-258
924-323
2 Rear panel cable clamp (25 each)
Rear panel cable clamp (5 each)
16. 008-930 2 Screw, socket button cap 4-40 x ¼” (with
hardware)
17. 886-493 1 Rear panel
18. 580-179 1 Fan assembly (with cable)
19. 886-489 1 Battery cage
20. 032-909 4 Kep nut 4-40
Continued on next page
9-18 Rev. F
