Chapter 9: Spare Parts ABL77 Service Manual
Recommended Parts and Hardware, Continued
Hardware
starter kit
This table lists all of the spare hardware parts that are contained in the Hardware
Starter Kit (REF: 905-735). Each of these parts may be ordered separately as a
pack containing the quantity listed (∆ = exclusive to the SenDx 100 and ABL70).
REF Qty. Description
958-183 100 Hex cap, nylon ∆
856-644 10 Hinge, Printer Chassis
032-914 100 Nut, 2-56
032-912 100 Nut, hex ¼-28
032-908 100 Nut, hex 10–32
032-907 100 Nut, hex 4-40
032-906 100 Nut, hex 6-32
032-909 100 Nut, Kep 4-40
032-910 100 Nut, Kep 6-32
835-475 100 O-ring
924-170 100 Retaining ring (E-clip)
855-155 50 Rubber feet
008-925 100 Screw, #4 x
3
/
8
”
008-936 100 Screw, 4-20 x ¼”
001-908 100 Screw, button cap 4-40 x ¾” ∆
008-923 100 Screw, button head cap 6-32 x
5
/
16
”
008-922 100 Screw, button head cap 6-32 x
7
/
8
” ∆
008-928 100 Screw, button hex 4–40 x ¼”
008-921 100 Screw, machine tap pan head Phillips
008-935 100 Screw, machine 2-56 x ¾”
008-934 100 Screw, machine 2-56 x
3
/
8
”
008-929 100 Screw, pan head Phillips 4-40 x
7
/
8
”
008-926 100 Screw, pan head Phillips m2.5 x 20
008-932 100 Screw, pan head Phillips m2.5 x 6
008-937 100 Screw. pan head 4-40 x ¼”
008-938 100 Screw, pan head 6-32 x ¼”
008-927 10 Screw, panel, left
008-931 10 Screw, panel, right
Continued on next page
9-22 Rev. F
