R&S FSPN - Page 391

Remote Control
R&S
®
FSPN
391User Manual 1179.4363.02 ─ 01
Manual operation: See "Defining the video bandwidth" on page 137
11.6.9.4 Trigger Configuration
TRIGger[:SEQuence]:DTIMe...........................................................................................391
TRIGger[:SEQuence]:FREQuency...................................................................................391
TRIGger[:SEQuence]:FREQuency:HYSTeresis................................................................. 391
TRIGger[:SEQuence]:HOLDoff[:TIME]..............................................................................392
TRIGger[:SEQuence]:IFPower:HOLDoff...........................................................................392
TRIGger[:SEQuence]:LEVel[:EXTernal<1|2>].................................................................... 392
TRIGger[:SEQuence]:SLOPe.......................................................................................... 393
TRIGger[:SEQuence]:SOURce........................................................................................393
TRIGger[:SEQuence]:DTIMe <Time>
This command defines the trigger drop-out time.
Parameters:
<Time> <numeric value>
*RST: 0
Default unit: s
Example: //Define a drop-out time
TRIG:DTIM 200MS
Manual operation: See "Defining a trigger drop-out time" on page 135
TRIGger[:SEQuence]:FREQuency <Frequency>
This command defines the trigger frequency.
Prerequisites for this command
●
Select the frequency trigger (TRIGger[:SEQuence]:SOURce).
Parameters:
<Frequency> <numeric value>
Default unit: Hz
Example: //Configure frequency trigger
TRIG:SOUR FREQ
TRIG:FREQ 1GHZ
Manual operation: See "Defining the trigger level and frequency" on page 134
TRIGger[:SEQuence]:FREQuency:HYSTeresis <Hysteresis>
This command defines the trigger hysteresis.
Prerequisites for this command
●
Select the frequency trigger (TRIGger[:SEQuence]:SOURce).
Common Measurement Settings
