REXROTH IndraDrive C - Page 120

8-4 Electromagnetic Compatibility (EMC) Rexroth IndraDrive
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Limit Values for Line-Based Disturbances
According to IEC EN 61800-3 or CISPR 11, the limit values in the table
below are distinguished. For this documentation both standards are
combined in the limit value classes A2.1 to B1.
Limit value classes
IEC / EN 61800-3 CISPR 11 Explanation Limit value
class
2
nd
environment;
I >100A
Class A;
Group 2
I >100A
limit value in industrial areas to be complied with for applications
operated at supply mains with nominal currents > 100A
A2.1
2
nd
environment;
I <100A
Class A;
Group 2
I <100A
limit value in industrial areas to be complied with for applications
operated at supply mains with nominal currents < 100A
A2.2
1
st
environment;
restricted
distribution
Class A;
Group 1
Limit value in residential area or at facilities at low-voltage mains
supplying buildings in residential areas. To be complied with for
applications with restricted distribution.
A1
1
st
environment;
unrestricted
distribution
Class B;
Group 1
limit value in residential areas to be complied with for
applications with unrestricted distribution
B1
Fig. 8-4: Limit value classes
Limit value characteristic through frequency range
Limit values for line-based disturbances (DIN EN 61800-3/A11 /
DIN EN 55011
)
1.1
1.2
2.1
3.1
4.1
2.2
3.2
4.2
1.1
1.2
2.1
2.2
3.1
3.2
4.1
4.2
130
120
100
90
79
66
56
125
115
86
76
60
56
46
115
105
73
50
60
70
QSP
value
Second environment, I > 100A, QSP,
(industrial area: class A, group 2, I > 100A)
QSP
value
Second environment, I < 100A, QSP
(industrial area, class A, group 2, I < 100A)
Average
Value
Second environment, I < 100A, AV
(industrial area, class A, group 2, I < 100A)
QSP
value
First environment (1),
restricted distribution, QSP,
(class A, group 1)
Average
Value
First environment (1),
restricted distribution, AV,
(class A, group 1)
QSP
value
First environment (1),
unrestricted distribution, QSP
,
(class B, group 1)
Average
value:
First environment (1),
unrestricted distribution, AV
,
(class B, group 1)
Average
Value
Second environment, I > 100A, AV
(industrial area, class A, group 2, I > 100A)
(1)Limit value for first environment is also relevant
if source of interference of second environment
affects first environment.
QSP: measuring method quasi peak measurement
AV: measuring method arithmetic averaging
Fig. 8-5: Limit values for line-based disturbances
