6 Configuration of the Drive System
Rexroth IndraDrive
6.1 Allowed Combination of Individual Components in Drive
System Rexroth IndraDrive
Within the product range Rexroth IndraDrive you may combine
components of the subranges Rexroth IndraDrive C and
Rexroth IndraDrive M.
Allowed Combination of Range Components from IndraDrive M and
IndraDrive C
Drive controller or
supply unit
Range components
HMS01 HMD01 HCS02 HCS03
HMV01
X X
-- --
HCS02
XXX
--
HCS03
X X
--
X
X: allowed
--: not allowed
Fig. 6-1: Combination of range components
Allowed Combinations with Additional Components
Drive controller or
supply unit
HLB01.1C HLB01.1D
HLC01.1C HLC01.1D HLR01.1 HMF01.1
HMV01.1E
--
X X X
-- --
HMV01.1R
--
XX X
-- --
HCS02.1
X
tbd
X X X --
HCS03.1
tbd
tbd
--
X (1) XX
X: allowed
--: not allowed
(1) only allowed for HCS03.1E-...-W0210 (not allowed for W0070,
W0100, W0150)
Fig. 6-2: Combinations with additional components
