REXROTH IndraDrive C User Manual

Rexroth IndraDrive Introduction 1-15
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Selecting the Component for Mains Supply
Order with ascending continuous power.
Compact
converters
Modular
mains
supply
Type
current or
power
Contin.
power
"ON"
P
DC_cont
[kW] (1)
Peak
power
"ON"
P
DC_peak
[kW] (1)
Contin.
braking
power
[kW]
Max.
braking
power
[kW]
HCS02 -- E-W0028 4,2 10 0,15 10
HCS02 -- E-W0054 9,1 16 0,35 18
HCS02 -- E-W0070 13,3 19 0,5 25
-- HMV01 R-W0018 18 45 0,4 36
HCS03 -- E-W0070 20 40 opt. opt.
-- HMV01 E-W0030 30 45 1,5 36
HCS03 -- E-W0100 32 59 opt. opt.
HCS03 -- E-W0150 40 89 opt. opt.
-- HMV01 R-W0045 45 112 0,4 90
-- HMV01 R-W0065 65 162 0,4 130
-- HMV01 E-W0075 75 112 2 90
HCS03 -- E-W0210 59 124 opt. opt.
-- HMV01 E-W0120 120 180 2,5 130
opt. equipment to be optionally ordered
(1) with use of mains choke HNL01; at 3 AC 400 V
Fig. 1-14: Performance data of mains supply units
Note: The data of peak power and continuous power show the
maximum possible limit values. For the actually available
performance profiles please see the corresponding data
sheets.

REXROTH IndraDrive C Specifications

General

Protection Class	IP20
Voltage Range	200 V to 480 V
Input Voltage	200 to 480 VAC
Control Modes	Speed, Torque, Position
Communication Interfaces	PROFIBUS, CANopen, Ethernet
Feedback Systems	Resolver, incremental encoder, absolute encoder
