REXROTH IndraDrive C - 14.3 Shield Connection HAS02; Type Code

Rexroth IndraDrive Accessories in the Drive System Rexroth IndraDrive 14-27
DOK-INDRV*-SYSTEM*****-PR02-EN-P
14.3 Shield Connection HAS02
Accessories for appropriate connection of the motor cable to the drive
controller, especially the shield connection of the motor cable.
There are appropriate HAS02 available for the different connection cross
sections of the drive controllers.
Type Code
DT000004v01_en.fh
1234 6789
1
05 1234 67895
Example:
Abbrev.
Column
HAS02 . 1 -001 -NNN-NN
1. Product
1.1 Accessories
IndraDrive . . . = HAS
2. Line
2.1 Shield connection. . . .= 02
3. Design
3.1 1 . . . . . . . . . . . . . . . . . . . . . . = 1
4. Device assignment
4.1 HMS01.1N-W0020 . . . . . . . . . . . = 001
4.2 HMS01.1N-W0036 . . . . . . . . . . . = 001
4.3 HMS01.1N-W0054 . . . . . . . . . . . = 002
4.4 HMS01.1N-W0070 . . . . . . . . . . . = 002
4.5 HMD01.1N-W0020 . . . . . . . . . . . = 002
4.6 HMD01.1N-W0036 . . . . . . . . . . . = 002
4.7 HCS02.1E-W0012 . . . . . . . . . . . = 002
4.8 HCS02.1E-W0028 . . . . . . . . . . . = 002
4.9 HCS02.1E-W0054 . . . . . . . . . . . = 002
4.10 HCS02.1E-W0070 . . . . . . . . . . . = 002
4.11 HMS01.1N-W0150 . . . . . . . . . . . = 003
4.12 HMS01.1N-W0210 . . . . . . . . . . . = 003
4.13 HCS03.1E-W0070 . . . . . . . . . . . = 004
4.14 HCS03.1E-W0100 . . . . . . . . . . . = 005
4.15 HCS03.1E-W0150 . . . . . . . . . . . = 005
4.16 HNK01.1A-A075-E0050 . . . . . . . = 006
4.17 HNK01.1A-A075-E0080 . . . . . . . = 007
4.18 HNK01.1A-A075-E0106 . . . . . . . = 007
4.19 HCS03.1E-W0210 . . . . . . . . . . . = 008
4.20 HNK01.1A-A075-E0146 . . . . . . . = 009
5. Other feature
5.1 none . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NNN
6. Other design
6.1 none . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NN
Fig. 14-25: Type code HAS02.1
