5-8 Specifications for the Components of the Drive System Rexroth IndraDrive
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Power Voltage Supply
For the devices of the IndraDrive range, the specifications for supply with
power voltage contained in the table below are generally valid.
The indicated values represent the common standard range.
Standard range of power voltage
Designation Symbol Unit Values
allowed range of mains input
voltage, three-phase
U
LN
V 3 * AC (400..480) +10% -15%
rotary field no rotary field condition
allowed range of mains
frequency
f
LN
Hz (50 ... 60) + - 2
max. allowed mains frequency
change
d f
LN
/t Hz/s 2% * f
LN
Fig. 5-11: Standard range of power voltage
Depending on the device characteristic, the following extended range
can be used for power voltage supply.
Extended range of power voltage
Designation Symbol Unit HCS02.1E HMV-E
HMV-R
HCS03.1E
allowed range of mains input
voltage, three-phase
U
LN
V
3 * AC (200..500)
+-10%
3 * AC (400..480)
+10% -15%
3 * AC (400..500)
+10% -15%
allowed range of mains input
voltage, single-phase
U
LN
V
1 * AC (200..250)
+-10%
not allowed not allowed
Fig. 5-12: Extended range of power voltage
Note: When using HCS02 and HCS03 devices in the mains voltage
range up to 3 * AC 500 V, make sure the additional
components you use may be operated in this mains voltage
range. NFD mains filters, for example, can only be used up to
3 * AC 480 V.

REXROTH IndraDrive C Specifications

General

Protection Class	IP20
Voltage Range	200 V to 480 V
Input Voltage	200 to 480 VAC
Control Modes	Speed, Torque, Position
Communication Interfaces	PROFIBUS, CANopen, Ethernet
Feedback Systems	Resolver, incremental encoder, absolute encoder
