Combination HCS03 with HCS03 (Rexroth IndraDrive C)
Note: Group supply with DC bus connection is only allowed with
HCS03.1E drive controllers of the same type current.
Note: At HCS03.1E drive controllers, do not operate any external
additional capacitances at the DC bus.
Exceptions:
For drive controllers HCS03.1E-...-W0210 this is allowed.
Operating HAS accessories with capacitances against housing
is allowed.
Group Supply with DC Bus Connection HCS03 (Parallel
Operation)
Type of mains connect. (1) Maximum number of IndraDrive C components at common DC bus
HCS03.1E- HLB01.1 HLC01.1
group supply with DC bus
connection
W0070 W0100 W0150 W0210
HCS03.1E-W0070 10 --
-- --
--
--
HCS03.1E-W0100
--
8
-- --
--
--
HCS03.1E-W0150
-- --
6
--
--
--
HCS03.1E-W0210
-- -- --
4
--
take max. allowed
external DC bus
capacitance C
DCext
into account
--: not allowed
(1) for explanation see chapter
Fig. 6-9: Maximum number of IndraDrive C components at common DC bus
parallel operation of HCS03.1E:
• 6 * HCS03.1E-W00150
Central Supply HCS03
Central supply of HCS03.1E is not allowed with HCS03.1E drive
controllers.
Example
