Distances for Drive Controllers
In addition to the mounting dimensions, the components of the
Rexroth IndraDrive range require additional mounting clearance
• to ventilate the components
• to mount accessories and connections
• to take temperature limits of neighboring mounting parts, such as
cable ducts etc., into account
To determine the required mounting clearances in the control cabinet,
take additional distances between the components and on their tops and
bottoms into account.
Distance between Drive Controllers
Owing to power dissipation in the components, especially due to installed
braking resistors in compact devices, the temperatures of neighboring
components are rising. In the case of lateral mounting, trouble-free
operation therefore requires the following minimum distances in [mm]
between the components.
From device
to device
HCS02.1E HCS03.1E
with HNK01
and HLR01
HMV01.1E /
HMV01.1R
HMS01.1 /
HMD01.1
HCS02.1E 5 -- -- 5
HCS03.1E with
HNK01 and
HLR01
-- 0 -- 0
HMV01.1E /
HMV01.1R
-- -- 0 0
HMS01.1 /
HMD01.1
5000
-- not allowed
Fig. 7-5: Minimum distance in [mm]
Note: For arrangement of the components in the control cabinet,
take their dimension sheets and the required minimum
distances into account.

REXROTH IndraDrive C Specifications

General

Protection Class	IP20
Voltage Range	200 V to 480 V
Input Voltage	200 to 480 VAC
Control Modes	Speed, Torque, Position
Communication Interfaces	PROFIBUS, CANopen, Ethernet
Feedback Systems	Resolver, incremental encoder, absolute encoder
