10.5 Power Factors and Emitted Mains Harmonics of the
Device
Due to their electric design, the drive controllers and supply units
generate harmonics in the mains current and on the mains voltage during
operation at the mains. Using appropriate mains chokes decisively
influences power factors and mains harmonics.
Power Factors cosϕ1 (DPF) and cosϕ (TPF)
The power factors are decisively influenced by mains chokes.
Type of drive controller
or supply unit
Type of
mains
choke
3AC400V 3AC480V 3AC500V Notes
DPF
cosϕ1
TPF
cosϕ
DPF
cosϕ1
TPF
cosϕ
DPF
cosϕ1
TPF
cosϕ
W0012 without 0,97 0,59 tbd tbd tbd tbd
W0028 without 0,97 0,59 tbd tbd tbd tbd
W0054 without tbd 0,55 tbd tbd tbd tbd
W0070 without tbd 0,58 tbd tbd tbd tbd
W0012 HNL01 tbd -- tbd tbd tbd tbd
W0028 HNL01 tbd 0,83 tbd tbd tbd tbd
W0054 HNL01 tbd 0,77 tbd tbd tbd tbd
HCS02
W0070 HNL01 tbd 0,66 tbd tbd tbd tbd
W0070 without 0,64 0,57 tbd tbd tbd tbd
W0100 without 0,67 0,59 tbd tbd tbd tbd
W0150 without 0,7 0,61 tbd tbd tbd tbd
W0210 without 0,73 0,62 tbd tbd tbd tbd
W0070 HNK01 0,95 0,85 tbd tbd tbd tbd
W0100 HNK01 0,95 0,83 tbd tbd tbd tbd
W0150 HNK01 0,94 0,81 tbd tbd tbd tbd
HCS03
W0210 HNK01 0,93 0,78 tbd tbd tbd tbd
W0030 ohne tbd tbd tbd tbd tbd tbd
W0065 without tbd tbd tbd tbd tbd tbd
W0120 without tbd tbd tbd tbd tbd tbd
W0030 HNL01 tbd tbd tbd tbd tbd tbd
W0065 HNL01 tbd tbd tbd tbd tbd tbd
HMV01.1E
W0120 HNL01 tbd tbd tbd tbd tbd tbd
W0018 HNL01 tbd tbd tbd tbd tbd tbd
W0045 HNL01 tbd tbd tbd tbd tbd tbd
HMV01.1R
W0065 HNL01 tbd tbd tbd tbd tbd tbd
tbd: in preparation
U
N
: nominal voltage of mains between the conductors
Fig. 10-20: Power factor DPF, cosϕ1
