REXROTH IndraDrive C User Manual

4-4 Brief Description, Applications Rexroth IndraDrive
DOK-INDRV*-SYSTEM*****-PR02-EN-P
4.7 Control Sections CSH01, CSB01, CDB01
Applications
Control sections CSH, CSB and CDB are used to
• operate drive controllers HMS, HMD and HCS
The different control sections can be used as follows:
Device type Application
CSH01
Advanced
The CSH01 control section is used in HMS01, HCS02
and HCS03 drive controllers.
CSB01
BASIC single-axis
The CSB01 control section is used in HMS01, HCS02
and HCS03 drive controllers.
CDB01
BASIC double-axis
The CDB01 control section is used in HMD01 drive
controllers.
Fig. 4-6: Control section applications
4.8 Drive Controllers HCS02 and HCS03
Applications
Drive controllers HCS02 and HCS03 are used to
• operate single axes
The different drive controllers can be used as follows:
Device type Application
HCS02 HCS02 drive controllers
- have a power output to operate a motor.
- cover the power range from 1.5 kW to 11 kW.
HCS03 HCS03 drive controllers
- have a power output to operate a motor.
- cover the power range from 18 kW to 75 kW.
Fig. 4-7: Drive controller HCS applications

REXROTH IndraDrive C Specifications

General

Protection Class	IP20
Voltage Range	200 V to 480 V
Input Voltage	200 to 480 VAC
Control Modes	Speed, Torque, Position
Communication Interfaces	PROFIBUS, CANopen, Ethernet
Feedback Systems	Resolver, incremental encoder, absolute encoder
