Rexroth IndraDrive Specifications for the Components of the Drive System 5-1
DOK-INDRV*-SYSTEM*****-PR02-EN-P
5 Specifications for the Components of the Drive
System
5.1 Tests and Certifications
Note: For information on the current status of the certifications ask
our sales representative.
CEf1.fh7
Fig. 5-1: CE label
according to UL 508 C
The devices are listed under the term "Rexroth".
Note: For using the devices in the scope of C-UL, take the C-UL limit
values of the individual devices into account. In addition, take
the following aspects into account:
use 60/75°C copper wire only for mains connection
use Class 1 wire only or equivalent for mains connection
mains connection suitable for use on a circuit capable of delivering
not more than 8 kA (10 kA) rms symmetrical amperes for a maximum
voltage of 500 V (400 V)
c_ul_us.tif
Fig. 5-2: C-UL-US label
Note: The control sections are included in the listing of the power
sections. The control sections are not listed separately.
CE Label
C-UL-US Listing
