REXROTH IndraDrive C User Manual

4-6 Brief Description, Applications Rexroth IndraDrive
DOK-INDRV*-SYSTEM*****-PR02-EN-P
4.10 Braking Resistor HLR01
Applications
Braking resistors HLR01 are used to
• convert generated kinetic energy into thermal energy
The different braking resistors can be used as follows:
Device type Application
HLR01 are used in drive controllers of the
Rexroth IndraDrive C range;
for this purpose, the drive controllers have to be
equipped with a standard or optional brake chopper;
Fig. 4-9: DC bus resistor units HLR
4.11 DC Bus Capacitor Units HLC01
Applications
DC bus capacitor units HLC01 are used to
• store energy in the DC bus of the drive system
The different DC bus capacitor units can be used as follows:
Device type Application
HLC01.1C DC bus capacitor units HLC01.1C
- are used in drive systems of the product ranges
Rexroth IndraDrive C and M.
HLC01.1D DC bus capacitor units HLC01.1D
- are used in drive systems of the product ranges
Rexroth IndraDrive C and M.
Fig. 4-10: DC bus capacitor unit HLC applications

REXROTH IndraDrive C Specifications

General

Protection Class	IP20
Voltage Range	200 V to 480 V
Input Voltage	200 to 480 VAC
Control Modes	Speed, Torque, Position
Communication Interfaces	PROFIBUS, CANopen, Ethernet
Feedback Systems	Resolver, incremental encoder, absolute encoder
