14-4 Accessories in the Drive System Rexroth IndraDrive Rexroth IndraDrive
DOK-INDRV*-SYSTEM*****-PR02-EN-P
As adjusted to the device widths, the basic accessories are supplied with
or without contact bars.
HAS01 without contact bars and HAS01 with contact bars.
• Example 1: Without contact bars (-NNN).
• Example 2: With contact bars to interconnect the DC buses (e.g. -048
or -072); the bars are adjusted to the device width.
• Example 3: With contact bars to interconnect the DC buses (e.g. -048
or -072); the bars are adjusted to the device width. In addition, the joint
bars for connecting the equipment grounding conductors are
contained in this case.
Note: Please observe that the contact bars of the basic accessories
HAS01 are used for connection to the drive controller to the
left side.
Applications
The HAS01 accessories are used to
• to fasten the drive controllers on a mounting surface,
• interconnect the DC bus connections of drive controllers,
• connect the 24V supply of drive controllers of the
Rexroth IndraDrive M range,
• establish the connection of the equipment grounding conductors from
drive controller to drive controller or supply module.
