REXROTH IndraDrive C User Manual

Rexroth IndraDrive Requirements to the Mains Connection 10-9
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Maximum Allowed Mains Overvoltages
The devices were dimensioned only up to a certain level of mains over
voltage. Higher overvoltage has to be limited by other measures, e.g.
overvoltage protection on site.
Circuit Against
environment and
ground (1)
Between the
conductors within
the circuit (1)
mains connection 230...500 V 2 kV 1 kV
supply connection 24V and relay
contact connections
50 V 30 V
other connections U
N
+5% U
N
+5%
(1): impulse withstand voltage 1,2/ 50µs and 8/ 20 µs
Fig. 10-18: Maximum allowed mains overvoltages

REXROTH IndraDrive C Specifications

General

Protection Class	IP20
Voltage Range	200 V to 480 V
Input Voltage	200 to 480 VAC
Control Modes	Speed, Torque, Position
Communication Interfaces	PROFIBUS, CANopen, Ethernet
Feedback Systems	Resolver, incremental encoder, absolute encoder
