Rexroth IndraDrive Brief Description, Applications 4-5
DOK-INDRV*-SYSTEM*****-PR02-EN-P
4.9 DC Bus Resistor Unit HLB01
Applications
DC bus resistor units HLB01 are used to
convert generated kinetic energy into thermal energy
increase the continuous regenerative power in the drive system
increase the peak regenerative power in the drive system
have the DC bus short circuit function available in the drive system
The different DC bus resistor units can be used as follows:
Device type Applications
HLB01.1C HLB01.1C DC bus resistor units
- are used in drive systems with components of the
product range Rexroth IndraDrive C.
HLB01.1D HLB01.1D DC bus resistor units
- are used in drive systems with components of the
product range Rexroth IndraDrive M.
Fig. 4-8: DC bus resistor unit HLB applications
